Top Mould Base Design for Industrial
Product details of the mould base design
Product Overview
Ruifengda mould base design is famous for its finest materials which are sourced from qualified suppliers. The functionality of the product has been significantly optimized by our competent and dedicated researchers. mould base design is one of the main products of Ruifengda. With wide application, our product can be applied to different industries and fields. And it is deeply loved and favored by customers. Ruifengda Brand's design team will analyze the feasibility and cost of your customized project.
Product Introduction
Ruifengda guarantees mold base to be high-quality by carrying out highly standardized production. Compared with other products in the same category, it has the following advantages.
|
Tolerance |
0.02mm-0.005mm |
Rust prevention measures |
Anti rust oil, anti rust spray, vacuum packaging... |
|
Mould life |
300000-500000 Shots |
Transaction mode |
FOB/CIF |
|
Major equipment |
YASDA, OKUMA |
Testing |
CMM, Opening and closing activities... |
|
Size |
Customer Size Accepted |
Runner |
Hot runner |
|
Minimum order quantity |
1 Set |
Supply ability |
300-400 sets per month |
|
Material Science |
S50C, P20, 1.2311, 718H, 4Cr13H, 420H, S136H ... |
Payment method |
T/T, Paypal, Cash |
|
Packing |
Wooden box, plastic film |
OEM |
Available |
Accessories
All accessories of mould base can be provided according to the drawings. We can provide standard and nonstandard accessories such as HASCO, MISUMI, PUNCH, DME and LKM. Also, we process special accessories including bronze accessories, ball cage bush, self-lubricating parts, etc.
Cavity and core plates
The parallelism and verticality of pocket should be controlled within 0.02mm. The length, width, and depth tolerance of the precision mould base should be 0~+0.02mm, and the thickness tolerance of the main plates should be ± 0.02mm. These are the minimum standard. Precision machining is required for screw holes, water line holes, ejector pin holes, nozzle holes, etc. All surfaces should be scratch free, bright and flat, all chamfers should comply with our company's standards and should be uniform. In the actual machining process, corresponding precision requirements will be formulated based on specific mold design and customer needs.
CNC Machining
We have over ten CNC equipment from brands such as YASDA and OKUMA to meet the high-precision requirements of our customers. Taking YASDA as an example: constant temperature workshop 22 ℃, accuracy 0.003mm, machine travel 900X1500X600mm.
Testing
We use CMM coordinate measurement and generate accurate measurement reports. Its high-precision measurement results can ensure product quality and tolerance requirements.
Anti-corrosion treatment
In order to reduce the impact of rust on mould base during shipping, we will use anti rust spray and anti rust oil on the surface of mould base, and then wrap them with plastic film. If necessary, vacuum packaging will be used.
fAQ
Company Information
Ruifengda Brand is located in shen zhen. And the major business is focused on the production and sales of mold base. With the business philosophy of 'technological innovation, cooperation and win-win, integrity and efficiency, service first', our company sets up strict management standards and takes constant innovation, and is committed to becoming the most professional enterprise. Ruifengda brings together many middle and senior technical talents who have worked hard for many years in the industry. Ruifengda has many years of industry experience and strong production strength. According to different needs of customers, we are able to provide customers with excellent and efficient one-stop solutions.
We are willing to go hand in hand with you to create a better future.
